Samsung 9100 PRO 1TB - PCIe Gen5 x4 M.2 NVMe SSD - MZ-VAP1T0BW

Application: Client PCs, Game Consoles
Rated Capacity: 1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor: M.2 (2280)
Interface: PCIe® 5.0 x4, NVMe™ 2.0
Dimension (WxHxD): Max 80.15 x Max 22.15 x Max 2.38 mm
Weight: Max 9.0g Weight
Storage Memory: Samsung V-NAND TLC
Controller: Samsung in-house Controller
Cache Memory: Samsung 1GB Low Power DDR4X SDRAM
TRIM Support: Supported
S.M.A.R.T Support: Supported
GC (Garbage Collection): Auto Garbage Collection Algorithm
Encryption Support: AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support: Not supported
Device Sleep Mode Support: Yes
Sequential Read: Up to 14,700 MB/s * Performance may vary based on system hardware & configuration
Sequential Write: Up to 13,300 MB/s * Performance may vary based on system hardware & configuration
Random Read: Up to 1,850,000 IOPS * Performance may vary based on system hardware & configuration
Random Write: Up to 2,600,000 IOPS * Performance may vary based on system hardware & configuration
Average Power Consumption (system level): Average: Read 7.6 W / Write 7.2 W* Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Idle): Typical 4 mW * Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Device Sleep): Typical 3.3 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage: 3.3 V ± 5 % Allowable voltage
Reliability (MTBF): 1.5 Million Hours Reliability (MTBF)
Operating Temperature: 0 - 70 ? Operating Temperature
Shock: 1,500 G & 0.5 ms (Half sine)
Installation Kit: Not Available
Management Software: Magician Software for SSD management
Warranty: 5-year Limited Warranty or 600TBW Limited Warranty
